Description
Technical Specifications
Used as control or Globe Valve in boilers, district heating and refrigeration equipment, cooling towers, heating units and air conditioning units. Suitable for open and closed circuits (note to avoid cavitation)
With flanged connections to ISO 7005
Can be equipped with electric actuator SAX..Or electro-hydraulic actuator SKD.., SKB.., SKC..
Size: DN15~DN150
Pressure Rating: PN16~PN25
Stroke: To DN 50: 20 mm, From DN 65: 40 mm
Body material: Carbon steel, Nodular cast iron
Seat Leakage：0…0.01% of the kvs value
Temperature Range:-20…220 °C
Rangeability: DN 15, kvs ≤ 1,25 m³/h: >50 , DN 15...150: >100
Permissible operating pressure:2500 kPa abs
