Description
Technical Specifications
Used as control or Globe Valve in boilers, district heating and refrigeration equipment, cooling towers, heating units and air conditioning units. Suitable for open and closed circuits (note to avoid cavitation)
With flanged connections to ISO 7005
With actuator SKC..Electro-hydraulic actuator assembly
Size: DN65~DN250
Pressure Rating: PN16
Stroke:40mm
Body material: Carbon steel, Nodular cast iron
Seat Leakage：0…0.01% of the kvs value
Temperature Range:-20…220 °C
Rangeability: >100
Permissible operating pressure:1600 kPa abs
