SPECS T Type Strainer is widely used in pipelines such as steam, air, water, oil and other media. It protects all kinds of equipment on pipeline system, such as pumps, valves, etc., and prevents pipes from blockage and damage from rust and slag. T Strainer has strong anti fouling performance, convenient pollution discharge, circulation area, small pressure loss, simple structure, small size and other characteristics; the filter screen material of T type filter is stainless steel, strong corrosion resistance, long service life; T Strainer is divided into DC and baffled the filter, the density of 10 mesh 120 mesh, temperature is 0~450 DEG C, according to user's needs.
Design Features:
1. Filter area is more bigger than nominal diameter,more bigger than Y-strainer and T-strainer.
2. Remove the solid of liquid to protect the working of machine is normal, and prolong the service time and protect the whole system.
3. Suitable medium: water, oil, steam, and corrosive material of chemical production. Beer, beverage, etc.
4. Working temperature: -80℃ — +450℃.
Applicable Standard:
Design Standard: ASME B16.34
Face to face: API6D, ASME B16.10
End Connection: ASME B16.5
Inspection and Test: API 598
Products Range:
Size: 2"~40"(DN50~DN1000)
Pressure Rating: ASME CLASS 150~300(PN16~40)
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel.
Screen: SS304, SS316, SS316L.
