Description
Technical Specifications
SPECS sanitary three way Control Valves are divided into three-way diversion and three-way combined flow. Suitable for food, pharmacy, cosmetics, clean steam, alcohol, beverage, biochemical industrial process control occasions, the product fully complies with EHEDG specifications and 3AS
Applicable Standard
Design & Manufacture Standard: EHEDG specifications and 3AS standards.
Face to Face: Manufacturer's standard
End Connection: ASME B16.5, ASME B16.11-2009
Test Standard: IEC60534-4
Products Range
Size: 3/4" ~ 4"
Pressure Rating: ASME CLASS 150
Material: Stainless Steel, Alloy Steel, Duplex Steel
End: Clamp type, Threaded type, Flange type
Temperature Range:-20℃~150℃
Seat Leakage：ANSI Ⅳ(0.01%) or Ⅵ(bubble-tight)
Cv: 6.3~175
Flow Characteristic: EQ%, Linear
Design Features
Pneumatic diaphragm actuator
Made of all stainless steel, clean and non-corrosive
Self-draining angular structure
Perfect support for CIP cleaning and SIP disinfection system
Perfect support for the WFI system of sterile water for injection
PDA certified seals to ensure clean working conditions
The surface of the valve body is electronically polished, and the surface roughness can reach 0.4 microns
