Pressure Seal Globe Valves are intended for high pressure,high temperature applications in all types of fluid except where severe coking is factor. The design and material selections provide excellent service in steam-generation stations,industrial chemical plants and thermal power plants.
Design Features
Straight pattern body design
Outside Screw and Yoke
Pressure Seal
Rising stem
Loose disc, choice of plug or ball
Renewable seat ring or Body seat ring
Full Port Or Reduced Bore
Low emission graphite gland packing
Size: 2" ~ 24"
Pressure Rating: ASME CLASS 600~1500
Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
Design & Manufacture Standard: BS 1873, ASME16.34
Face to Face: ASME B16.10
End Connection: ASME B16.5, ASME B16.25
Test Standard: API598
Operation: Manual, Pneumatic, Electric
Connection Type:Flange,Welding
