Pneumatic Cylinder Actuator provides double-acting and spring return pneumatic cylinder actuators characterized by large output and high-performance. Combined with linear stem motion type Control Valves,including Globe Valves,cage valves and Gate Valves,the actuators of this series are suited for modulating and on-off services.
Action Type: Air To Open, Air To Close, Double Actions
Products Size: 22#，23#，34#，45#，56#
Spring Range: 160~320kPa
Rated Sroke Range:16~150mm
Suitable Ambient Temperature Range: -30~70℃, -40~100℃
Handwheel Type: Top Mounted,Side Mounted
