SPECS PFA Lined Plug Valves are valves with cylindrical or conically tapered "plugs" which can be rotated inside the valve body to control flow through the valve,normally that’s reduce bore(different with Ball Valve),but also can make it as full bore design.
Applicable Standard
Design Standard: API 599,6D, ASME B16.34
Face to Face: ASME B16.10
End Flange: ASME B16.5
Butt welding Ends: ASME B16.25
Inspection and Test: API 598, API 6D
Products Range
Size: 1/2" ~14" (DN15 ~ DN350)
Rating: 150lb ~300LB
Body Material: Carbon Steel
Plug Material: Carbon Steel Lined PFA
Lining Material: PFA
Operation : Lever, Gear, Electric, Pneumatic, Hydraulic
Design Features
Reduced port or Full port
Rugged,Heavy-Duty Body
Large port opening
Non-Lubricated
