SPECS Jacketed Plug Valve are designed to control special chemical service where media has to be required within a specified temperature range. The steam jacketed design prevents the media in the body from cooling down. If cool media become solid, the trim parts, plug and stem will be very hard to operate. The steam jacket keep maintaining required temperature of the valve.
Applicable Standard
Design Standard: API 599,6D, ASME B16.34
Face to Face: ASME B16.10
End Flange: ASME B16.5
Butt welding Ends: ASME B16.25
Inspection and Test: API 598, API 6D
Products Range
Size: 1/2" ~14" (DN15 ~ DN350)
Rating: 150lb ~300LB
Body Material: Carbon Steel
Plug Material: Carbon Steel
Sleeve Material: PTFE
Operation : Lever, Gear, Electric, Pneumatic, Hydraulic
Design Features
Reduced port or Full port
Rugged,Heavy-Duty Body
Large port opening
Non-Lubricated
