Description
Technical Specifications
Forged Check Valves,its produced one piece that’s stronger than an equivalent casted parts.like all Check Valves, are used to prevent back flow in the line. The pressure of the fluid passing through a system opens the valve, while any reversal of flow will close the valve.
Design Features
T-pattern or Y pattern
Bolted bonnet or Welded bonnet
Full bore or Reduce bore
Integral body seat for piston or ball check
Type: Swing, Piston, Ball Check
Size: 1/4" ~ 2"
Pressure Rating: 800LB, 1500LB, 2500 LB
Material: A105N, LF2, F11, F22, F304, F316, F304L, F316L, F317
End: NPT, SW, RF, RJT, BW
Design & Manufacture Standard: API 602, BS5352
Face to Face: ASME B16.10
End Connection: ASNI B16.11(SW), ASNI B1.20.1(NPT), ANSI B16.25(BW)
Test Standard: API598
