Cast Steel Swing Check Valves, like all Check Valves, are used to prevent back flow in the line. The pressure of the fluid passing through a system opens the valve, while any reversal of flow will close the valve. The swing check valve functions by allowing flow forces to move the closure element, it is a hinged clapper which swings or rotates around a supporting shaft.
Design Features
Bolted bonnet
Swing type disc
Damper & Counter weight for options
Inside pin reduces leakage
Size: 2" ~ 36"
Pressure Rating: ASME CLASS 150~2500
Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
End: BW, RF, RTJ
Design & Manufacture Standard: BS 1868, ASME16.34, API 6D
Face to Face: ASME B16.10, API 6D
End Connection: ASME B16.5, ASME B16.25
Test Standard: API598, API 6D
