Cast Globe Valve are follow with BS1873 standard and widely used in in many industrial applications including the oil and gas industry, pharmaceutical, manufacturing, automotive, and marine, etc. Globe valves are also recommended for services requiring frequent operation and positive shut off.
Design Features
Straight pattern body design
Outside Screw and Yoke
Bolted Bonnet
Rising stem
Loose disc, choice of plug or ball
Renewable seat ring or Body seat ring
Size: 2" ~ 24"
Pressure Rating: ASME CLASS 150~1500
Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
Design & Manufacture Standard: BS 1873, ASME16.34
Face to Face: ASME B16.10
End Connection: ASME B16.5, ASME B16.25
Test Standard: API598
Operation: Manual, Pneumatic, Electric
Connection Type:Flange,Welding
