SPECS VALVE BB Forged Globe Valves are designed and manufactured to provide maximum service life and dependability. Valves are available in a complete range of body/bonnet materials and trims, we manufactures forged steel Globe Valve in three kinds bonnet design—Bolted Bonnet,Welded Bonnet and Pressure Sealed Bonnet.
Design Features
OS&Y
Bolted bonnet or Welded bonnet
Full bore or Reduced bore
T-pattern or Y-pattern
Integral backseat
Size: 1/2" ~ 2"
Pressure Rating: ASME CLASS 150~1500
Materials:A105,LF2,F91,F11,F22,F304,F304L,F316,F316L,F321,F51,Alloy steel etc.
Trim: Per API 602
Operation: Handwheel
Connection Type:Flange,Welding,Thread, Socket welding
