SPECS API602 Y-type strainer is a small device that removes a small amount of solid particles in the liquid, which can protect the normal operation of the device. When the fluid enters the filter cartridge with a certain size of filter screen, its impurities are blocked, and the clean filtrate is filtered. The outlet of the device is discharged. When cleaning is required, just remove the detachable filter cartridge and reload it after treatment. Therefore, it is extremely convenient to use and maintain. Y-type strainer also known as decontamination device and filter valve, is an indispensable device of the pipeline system for conveying medium. Its function is to filter mechanical impurities in the medium, and it can prevent rust, sand particles in the sewage, and a small amount of solids in the liquid. Particles, etc. are filtered to protect the fittings on the equipment pipeline from wear and blockage, which can protect the normal operation of the equipment.
Design Features:
1.Y type strainer
2.Non operation
3.Reduced Bore or Full Port,
4.Socket Welded,Threaded,Butt Welded,Flanged End
5.SW, NPT, RF or BW
6.Bolted Bonnet
Applicable Standard:
Design Standard: API602
Face to face: MFG'S
End Connection: - Flange Ends to ASME B16.5
- Socket Weld Ends to ASME B16.11
- Butt Weld Ends to ASME B16.25
- Screwed Ends to ANSI/ASME B1.20.1
Inspection and Test: API 598
Products Range:
Size: 1/2"~2"
Pressure Rating: Class 800, Class 150 to Class 2500
Body Materials: Forged (A105, A182 F304, F304L, F316, F316L, F51, F53, A350 LF2, LF3, LF5)
